Produkto specifikacijos:
Produkto kodas: LAMPGM&RG520F-EU
Architecture: ARM 64bit
CPU: 88F3720
CPU core count: 2
CPU nominal frequency: 800 MHz
CPU Threads count: 2
RouterOS license: 3
Operating System: RouterOS v7
Size of RAM: 512 MB
Storage size: 32 MB
Storage type: FLASH
MTBF: Approximately 200'000 hours at 25C
Tested ambient temperature: -40°C to 70°C
Powering
Number of DC inputs: 1 (PoE-IN)
Max power consumption: 10 W
Max power consumption without attachments: 10 W
PoE in: 802.3af/at
Cooling type: Passive
PoE in input Voltage: 12-56 V
Ryšys
3G kategorija: R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
3G dažniai:
1 (2100 MHz), 5 (850 MHz), 8 (900 MHz)
LTE katerija: CAT20 (DL: 2.0 Gbps; UL: 200 Mbps)
MIMO DL: 4x4
MIMO UL: 2x2
LTE FDD dažniai:
1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz), 28 (700 MHz), 32 (1500 MHz)
LTE TDD dažniai:
38 (2600 MHz), 40 (2300 MHz), 41 (2500 MHz), 42 (3500 MHz), 43 (3700 MHz)
5G NSA FDD dažniai:
1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz), 28 (700 MHz)
5G NSA TDD dažniai:
38 (2600 MHz). 40 (2300 MHz), 41 (2500 MHz), 75 (1500 MHz), 76 (1500 MHz), 77 (3700 MHz), 78 (3500 MHz)
5G SA FDD dažniai:
1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz), 28 (700 MHz)
5G SA TDD dažniai:
38 (2600 MHz), 40 (2300 MHz), 41 (2500 MHz), 75 (1500 MHz), 76 (1500 MHz), 77 (3700 MHz), 78 (3500 MHz)
Ethernet'as
10/100/1000 Ethernet port'ai: 1
Number of 1G Ethernet ports with Reverse PoE: (PoE-in): 1
Jungtys
SIM lizdų kiekis: 1 Modemas (Micro SIM)
Number of M.2 slots: 1
Kita
eSIM: Taip
Sertifikavimas
Certification: CE, EAC, ROHS
IP: 67
